Spec

• Operating temperature range: 400 °C, to 1,100 °C
• Maximum normal temperature: 1,050 °C
• Temperature Adjustment Precision: ± 2 °C at 1,050 °C
• Temperature distribution accuracy: ± 5 °C at 600 °C, to 1,000 °C
• Temperature rise time: about 30 minutes (R.T. 1,100 °C)
• Degree of vacuum reached: 8.3 Pa (vacuum reference)
• Atmosphere, vacuum, inert gas
• Ambient operating temperature: 5 °C, to 35 °C
• temperature controller: Microcomputer PID Control (Easy Program Controller)
• Operation form : Program Operation (10 patterns in 20 steps, pattern linking possible, vacuum pumps gas switching automatic Operation possible)
• Temperature sensor: R class thermocouple
• Heater: Nickel-Chrome
• Heater capacity: 2.5 kW
• Record Meter: For Temperature and Vacuum Degree: Record Width 100 mm RBI Type Chart Speed 10 mm/h to 1,500 mm/h (28 Stage Switching)
• Vacuum pumping system: oil rotation vacuum pumps 85 L/min (50Hz), 103 L/min (60Hz)
• Vacuum Gauge: Digital Pressure Switch
• Gas flow rate Meter: Digital Display Type Nitrogen Gas flow rate Meter: Up to 2 L/min Units * Please inquire if you would like other inert gases.
• Furnace Pressure Setting: Digital Type
• Furnace Body: Ceramic Fiber
• Door Packing: Silicone Rubber
• Safety device: Self-diagnostic function (Overheat, Temperature Sensor Disconnection, Heater Disconnection, SSR Short Circuit, Pro dark blue Malfunction, Air Cooled Fan Malfunction), motor overload protection, overcurrent/earth leakage breaker
• External input/output signal terminal: RS -485
• Furnace inner size: W 150 mm x D 250 mm x H 100 mm (H 75 mm)
• external dimensions : W 500 mm x D 750 mm x H 820 mm
• Furnace internal volume: about 3.8 L
• power supply (50Hz/60Hz): 200 VAC Single-phase 17 A
• Required power supply Equipment: 200 VAC Single-Phase 20 A
• Mass: about 133 kg
• Accessories: Hearth Plate 1 piece
