Spec

• Operating temperature range: 100 °C, to 1,150 °C
• Maximum normal temperature: 1,100 °C
• Temperature Adjustment Precision: ± 1.5 °C at 1,150 °C
• Temperature distribution accuracy: ± 3 °C at 1,000 °C
• Temperature rise time: about 70 minutes, from R.T. to 1,150 °C
• Ambient operating temperature: 5 °C, to 35 °C
• temperature controller: Microcomputer PID Control (TC-SVI System)
• Operation type: Standard Operation, Program Operation (maximum 100 steps) 1 minute, to 99 hours 59 minutes
• Temperature sensor: R class thermocouple
• Heater: iron - Chrome (Pyromax ® DS)
• Heater capacity: 900 W
• Furnace Body: Ceramic Fiber
• Safety device: Self-diagnostic function (Overheat, Temperature Sensor Error, Heater Disconnection, SSR Short Circuit, Ambient Temperature Error, temperature controller Error), control circuit protection f***, key lock function, overcurrent/leakage breaker, door switch, indep***ent overheat prevention device
• Furnace inner size: W 100 mm x D 180 mm x H 110 mm (H 100 mm)
• external dimensions : W 430 mm x D 495 mm x H 600
• Furnace internal volume: about 2 L
• Exhaust Port: φ 16 mm
• power supply (50Hz/60Hz): 200 VAC Single-phase 4.5 A
• Required power supply Equipment: 200 VAC Single-Phase 15 A
• Mass: about 32 kg
• Accessories: Furnace Plate 1 piece, Exhaust Lid 1 piece, Fixed metal bracket 2 pieces (Mounting Screw 4 pieces)
